Pro Series 5 Installation and Operation
Audio-Technica U.S., Inc.
1221 Commerce Drive, Stow, Ohio 44224 USA +1 (330) 686-2600
Audio-Technica Limited
Old Lane, Leeds LS11 8AG England +44 (0) 113 277 1441
Audio-Technica (Greater China) Limited
Unit K, 9/F., Kaiser Est. (Ph.2) 51 Man Yue St. Kowloon, HK. +852-2356-9268
Audio-Technica (S.E.A.) Pte. Ltd.
No 1 Ubi View, #01-14 Focus One, Singapore 408555 +65-6749-5686
Audio-Technica Corporation
2206, Naruse Machida, Tokyo Japan
©2012 Audio-Technica U.S., Inc. audio-technica.com P52430
Specications
OVERALL SYSTEM
UHF Operating Frequency 542.125 MHz to 561.250 MHz
Number of Channels 8
Frequency Stability ±0.005%, Phase Lock Loop Frequency
control
Modulation Mode FM
Maximum Deviation ±25 kHz
Operating Range 200’ typical
Operating Temperature Range 40º F (4ºC) to 110º F (43º C)
Frequency Response 100 Hz to 12 kHz
RECEIVER
Receiving System Antenna Switching Diversity
Image Rejection 55 dB minimum
Signal-to-noise Ratio >80 dB at 10 kHz deviation (IEC
weighted), maximum deviation 25 kHz
Total Harmonic Distortion ≤1% (10 kHz deviation @ 1 kHz)
Sensitivity 25 dBµV (S/N 60 dB at 10 kHz deviation,
IEC-weighted)
Audio Output
Unbalanced 211 mV (-13.5 dBV) (1 kHz modulation,
10 kHz deviation)
Balanced 150 mV (-16.5 dBV) (1 kHz modulation,
10 kHz deviation)
Output Connectors
Unbalanced
1
/
4
” TS (“mono”) phone jack
Balanced XLRM-type
Power Supply 100-240 VAC (50/60 Hz) to 12V DC 1A
(center positive) switched mode, external
power supply
Dimensions 7.48” (190.0 mm) W x 1.65” (42.0 mm) H
x 5.12” (130.0 mm) D
Net Weight 12.9 oz (365 g)
Accessory Included Power supply
UNIPAK
®
TRANSMITTER
RF Power Output High: 10 mW; Low: 5 mW
Spurious Emissions Under Federal Regulations
Dynamic Range >100 dB, A-weighted
Input Connections High impedance, Low impedance, Bias
Batteries (not included) Two 1.5V AA Alkaline
Current Consumption High: 140 mA; Low: 130 mA, typical
Battery Life Approximately 8 hours (High); 10 hours
(Low), depending on battery type and use
pattern
Dimensions 2.56” (65.0 mm) W x 4.13” (105.0 mm) H
x 0.73” (18.5 mm) D
Net Weight (without batteries) 2.8 oz (80 g)
HANDHELD TRANSMITTER
RF Power Output 10 mW
Spurious Emissions Under Federal Regulations
Dynamic Range >100 dB, A-weighted
Microphone Element Dynamic Unidirectional
Batteries (not included) Two 1.5V AA Alkaline
Current Consumption 120 mA, typical
Battery Life Approximately 12 hours depending on
battery type and use pattern
Dimensions 9.65” (245.0 mm) long, 2.11” (53.5 mm)
diameter
Weight (without batteries) 9.1 oz (257 g)
Accessory Included AT8456a Quiet-Flex
™
stand clamp
†
In the interest of standards development, A.T.U.S. offers full details on its test methods to
other industry professionals on request.
Specifications are subject to change without notice.
