MediaPack
Analog Fast Track Guide 18 Document #: LTRT-59802
3.3 Accessing the Embedded Web Server
¾ To access the Embedded Web Server, take these 4 steps:
1. Open a standard Web-browsing application such as Microsoft™ Internet Explorer™ (Version
6.0 and higher) or Netscape™ Navigator™ (Version 7.2 and higher).
2. In the URL field, specify the IP address of the MediaPack (e.g., http://10.1.10.10); the
Embedded Web Server’s ‘Enter Network Password’ screen appears, shown in Figure 3-2.
Figure 3-2: Embedded Web Server Login Screen
3. In the ‘User Name’ and ‘Password’ fields, enter the username (default: “Admin”) and
password (default: “Admin”). Note that the username and password are case-sensitive.
4. Click OK; the ‘Quick Setup’ screen is accessed, shown in Figure 3-3 (MGCP), Figure 3-4
(H.323), and Figure 3-5 (SIP).
3.4 Basic Control Protocol Parameters
To configure the MediaPack basic control protocol parameters use the Embedded Web Server’s
‘Quick Setup’ screen.
• For MGCP refer to Section 3.4.1 on page 18.
• For H.323, refer to Section 3.4.2 on page 20.
• For SIP, refer to Section 3.4.3 on page 22.
When you have completed the above relevant section you are then ready to start using the
MediaPack. For information on how to fully configure the VoIP gateway, refer to the MediaPack
User’s Manuals.
Tip: Once the gateway is configured correctly, back up your settings by making a
copy of the VoIP gateway configuration (ini file) and store it in a directory on
your PC. This saved file can be used to restore configuration settings at a
future time. For information on backing up and restoring the gateway’s
configuration refer to Section 5 on page 26.
Note: The following configuring Sections from here up to and including Section
3.4.3 on page 22 apply individually to MGCP, H.323, or SIP.
MGCP configuring continues with Section 3.4.1 on page 18.
H.323 configuring continues with Section 3.4.2 on page 20.
SIP configuring continues with Section 3.4.3 on page 22.
