AudioControl ACM-1.300 User Manual

8
Quick Start Guide
Power Connections
Ground
Head Unit
Remote Amplifier
+12V Trigger
+12V
In this example, the head unit has a +12V trigger
output that is connected to the ACM-1.300 remote
input terminal. When the head unit is turned on, it
will turn on the ACM-1.300 amplier.
Alternatively, the GTO™ signal sense feature can
be used to gently turn on the ACM-1.300 amplier
when an audio input signal is detected. (The con-
nection to the ACM-1.300 remote input terminal is
not required when using the GTO™ signal sense.)
