AudioControl Avalon G4 User Manual

12
Rear Panel
12. AC Input – Connect the supplied AC
power cord securely to this input. Plug
the other end into an AC mains outlet
of the correct voltage rating for your
unit. They are either 100 -120 VAC (50
– 60 Hz) or 220 – 240 VAC (50 – 60 Hz);
look at the check box to see how your
unit has been congured. The voltage
setting is not user-settable. This unit is
a class 1 device, so it is recommended
that you do not defeat the safety
ground connection or use a power cord
that does not have the safety ground
pin.
The Avalon G4 draws an average of
400 watts with typical source material.
Make certain that it is plugged
directly into the wall outlet, or a surge
protector power strip with sucient
power rating. Since The Avalon G4
has remote power switching using the
trigger system, you can plug the unit
into an outlet that is always active.
13. AC Fuse – The main power supply fuse
may be checked or replaced.
WARNING: Make sure that the power
cord is unplugged from the AC mains
before checking or replacing the fuse.
Use a at-headed screwdriver to undo
the fuse carrier from the fuse holder.
Inspect the fuse and replace with the
exact same type indicated on the unit.
The use of any other type of fuse may
lead to an unsafe condition. If the
fuse blows again immediately, then
unplug the power cord and contact
our ne folks in customer service.
Do not open the unit, as there are
no user-serviceable parts inside, and
dangerous voltages exist.
