Page 15
General Specifications Audio Samples Frequencies
The M-NET supports samples frequencies in the range of 6 KHz to 48 KHz in
1 Hz increments. Any stream which contains samples frequencies outside this
range will not be supported.
Audio Codec Sample Resolution
All decoders use 32-bit internal precision and output 16-bit PCM except FLAC
and MP3 which output 24-bit PCM.
The FLAC decoder supports up to 24-bits/sample (not relevant for other
decoders since they represent the data in a different format).
Features
Internet radio supported over Wi-Fi and Ethernet, with the service provided
by vTuner
Audio streaming with DLNA compatible server
Playback of music file with USB memory stick
2.7’’ high contrast OLED display
iOS and Android Apps for the remote control
Ȕ
Ȕ
Ȕ
Ȕ
Ȕ
SPDIF Outputs Coaxial and Optical
Audio Formats AAC, AAC+, MP3. WAV, WMA, FLAC, LPCM
Display OLED 128 x 64 Pixels, dot matrix
Wi-Fi IEEE 802.11a/b/g or n
Wi-Fi Encryption WEP, WPA, WPA2
Ethernet IEEE 802.3, 10 Base T or 100 Base T
USB USB 1.1, <1A
File Format FAT/FAT32
Internet Radio provider vTuner
DLNA V1.5, DMP & DMR supported
Power adaptor input 12V DC, 1.0A
Power Consumption
2.0W (Power On)
<1W (Standby)
Dimensions (L x W x H) 396 x 344 x 153mm
Weight Net: 1.9kg / Shipping: 2.9kg
Audio Maximum Bit-rate Specification
LPCM 1.536mbit/s
FLAC 1.5mbit/s
AAC/AAC+ 320kbit/s
MP3 320kbit/s
WMA 320kbit/s
