Audiovox KCD3180 - Front Panel Controls; Remote Control Overview

- 9 -
FRONT PANEL CONTROLS
1
2
34 5
6
7
8
9
11
1213
14
15
16
17
10
1. CD Drawer
2. LCD Display
3. Remote Control Sensor
4. POWER (ON/STANDBY) button
5. REPEAT/PRESET button
6. CLOCK SET/MEMORY button
7. TIMER/ON/OFF · SET button
8. TUNING · SKIP/TIMER + button
9. PLAY/PAUSE button
10. VOLUME+/- button
11. STOP/BAND button
12. TUNING · SKIP/TIMER - button
13. CD · RADIO FUNCTION button
14. DISP (Display) button
15. LIGHT ON/OFF switch
16. OPEN/CLOSE button
17. Countertop Light
REMOTE CONTROL
1. POWER button
2. TUN- • SEARCH button
3. STOP/BAND button
4. MEMORY/CLOCK SET button
5. FUNCTION button
6. REPEAT/PRESET+ button
7. TUN+ • SEARCH button
8. PLAY/PAUSE button
9. DISPLAY button
10. VOLUME+/- buttons
1
2
3
4
5
7
8
9
10
6
