Input Impedance: Low-Level 10K Ohms
High-Level 100 Ohms
Input Sensitivity: Low-Level 200 mV - 8 V.
High-Level 2V - 10 V
Filter type: Selectable High/Full/Low-pass
Crossover @12 dB / Octave
Filter Crossover: LPF 50-250 Hz (variable)
HPF 50-250 Hz (variable)
Supply Voltage: 12 volts, negative ground
Fuse Rating: 15 amps.
Dimensions (W X H X D): 295 mm X 54.3 mm X 228.6 mm
11-5/8" X 2-1/8" X 9”
Maximum Output Power: 500 Watts
125 Watts RMS x 2
@ 4 Ohms
Output Impedance: 2 - 8 Ohms (stereo)
Frequency Response: 10 - 35KHz +/-1 dB
Channel Separation: 60 dB
Signal / Noise Ratio: 90 dB
* Due to continuing improvement, Audiovox reserves the right to change features and design without notice.
-3-
This power amplifier has been designed to provide high Quality performance with a
minimum of maintenance. However, it's performance will only be as good as the care
and quality of components with which it is installed. We therefore advise that you
read these instructions very carefully to familiarize yourself with the product and it's
features.
Should you require assistance with the installation or wiring so this unit, please call
our toll-free "HELP" line at 1-800-645-4994 during the days/hours shown.
HELP!
1-800-645-4994
Monday-Friday 8:30am - 7:00pm Eastern
Saturday 9:00am - 5:00pm Eastern
HIGH PERFORMANCE STEREO AMPLIFIER
SPECIFICATIONS
