-9-
CAR STEREO
GROUND
BATTERY
FOR 12 VOLT USE ONLY
AUTO-ANTENNA LEAD
GROUND METAL
SECTION OF VEHICLE
EXISTING SCREW OR BOLT CLEAN PAINT, RUST, DIRT
OR GREASE FROM AREA FOR GOOD CONNECTION.
RIGHT
SPEAKER
2-8 OHM
LEFT
SPEAKER
2-8 OHM
OUTPUT WIRING DIAGRAM
LEFT RIGHT
REMBATT GND
FUSEFUSE
BRIDGEDBRIDGED
USE #10 GAUGE
WIRE (SEE TEXT)
