alpha Configuration Suite User Manual
Page 31 of 33
21003-1.2
Instruction Definitions
SIU
#SIU,a,b,c,d,e,f,g,h,i;
a – SIU Number (1 to 8)
b – Button Number (1 to 16)
c – Source Matrix (1)
d – Source Port (1 –16)
e – Destination Matrix (0 or 1)
f – Destination Port (0 to 16)
g – Button Priority (1 to 255)
h – Override (Zone or Button)
i – Message Id Number (0 to 30)
Note:
If the destination port is set to zero, then the button has been configured to select a message.
Other buttons can be configured on the same SIU to route this selected message to the
different destination zones.
INPUT Definition
#INPUT,a,b,c,d,e,f,g,h,i,j;
a – Input Number (1 to 16)
b – Input Port Number (3 or 4)
c – Input Bit Number (1 to 8)
d – Source Matrix (1)
e – Source Port (1 to 16)
f – Destination Matrix (0 or 1)
g – Destination Port (1 to 16)
h – Priority (0 to 255)
i – Override (Zone or Button)
j – Message Id Number (0 to 30)
SIU Definition
#SIUDEF,a,b,c,d,e,f,g;
a – SIU Name
b – SIU Number (1 to 8)
c – SIU Fault Reporting (Fault Reporting On = 1, Fault Reporting Off = 0)
d – SIU Communications Retries (1 to 16)
e – SIU Communications Response Timeout (1 to 1000)msec
f - SIU Fail Poll Rate (1000 to 3000)msec
g - SIU Normal Poll Rate (1 to 1000)msec
Input Definition
#INPUTDEF,a,b;
a – Input Name
b – Input Number (1 to 16)
