alpha Configuration Suite User Manual
Page 33 of 33
21003-1.2
Busy Definition
#BUSY,a,b,c,d,e,f;
a – Busy Signal Name
b – Busy Port Number (1 or 2)
c – Busy Bit Number (1 to 8)
d – Matrix Number (1)
e – Destination Port Number(1 to 16)
f – Busy Priority (0 – 255)
Live Definition
#LIVE,a,b,c,d,e;
a – Live Signal Name
b – Live Port Number (1 or 2)
c – Live Bit Number (1 to 8)
d – Matrix Number (1)
e – Source Port Number (1 to 16)
Wakeup Definition
#WAKE,a,b,c,d;
a - Wakeup Signal Name
b - Wakeup Id Number (1 to 16)
c - Wakeup Port Number (1 or 2)
d – Wakeup Bit Number (1 to 8)
Surveillance Definition
#SURVEY,a,b,c,d,e;
a – Wakeup Id Number (1 to 16)
b – Source Matrix (1)
c – Source Port (1 to 16)
d – Destination Matrix (1)
e – Destination Port (1 to 16)
Message Configuration
#MSGCFG,a,b,c,d,e,f,g,h,i,j,k;
a – Message Name
b – Message Id Number (0 to 30)
c – Source Matrix (1)
d – Source Port (1 to 16)
e – Message Segment Number (0 to 9)
f – Message Volume Level (0 to 63)
g - Message Bass EQ Level (0 to 63)
h – Message Treble EQ Level (0 to 63)
I – Surveillance Level (0 to 9)
j – Silence after end of Message (0 to 9) seconds
k – Mode, Message can be configured for ‘Play To End’( ) or ‘Play While Held’ ( )
Each message can be assigned a name, this is ignored by the alpha,
