AUMA Aumatic AC 01.1 Operation Instructions

Actuator controls AUMATIC AC 01.1 / ACExC 01.1
Profibus DP Operation instructions
10
4) Requires position transmitter in the actuator
6) For version in enclosure protection IP 68 higher corrosion protection KS or KX is strongly recommended
7) Distance between actuator and AUMATIC max. 100 m. Not suitable for version with potentiometer in the actuator. Instead of the potentiometer, a RWG has to be
used. Cable length for Non-intrusive version with MWG in the actuator max. 100 m. Requires separate data cable for MWG. If actuator and AUMATIC are
separated at a later date the max. cable length is 10 m.
8) Only in combination with reversing contactors and AUMATIC AC 01.1 in enclosure protection IP 67 or IP 68
Transmission speed/
cable length
Device types DP master class 1, e.g. central controllers such as PLC, PC, ...
DP master class 2, e.g. programming / configuration tools
DP slave, e.g. devices with digital and/or analogue inputs/outputs such as actuators,
sensors
Number of devices 32 devices without repeater, with repeater expandable to 126
Bus access Token-passing between the masters and polling for slaves.
Mono-master or multi-master systems are possible.
Supported Profibus DP functions Cyclic data exchange, sync mode, freeze mode, fail-safe mode
Service conditions
Enclosure protection according
to EN 60 529
Standard: IP 67 (when mounted)
Options: IP 68
6)
Terminal compartment additionally sealed against interior (double sealed)
Corrosion protection Standard: KN suitable for installation in industrial units, in water or power plants with
a low pollutant concentration
Options: KS suitable for installation in occasionally or permanently aggressive
atmosphere with a moderate pollutant concentration
(e.g. wastewater treatment plants, chemical industry).
KX suitable for installation in extremely aggressive atmosphere with
high humidity and high pollutant concentration
Finish coating Standard: two-component iron-mica combination.
Option: Special primer / special finish coat (customer’s choice)
Colour Standard: silver-grey (DB 701, similar to RAL 9007)
Option: Other colours as standard colour are possible on request
Ambient temperature – 25 °C to + 70 °C
Vibration resistance
according to IEC 60 068
1 g, from 10 Hz to 200 Hz
Weight approx. 7 kg (with AUMA plug/ socket connector)
Accessories
Wall bracket
7)
AUMATIC mounted separately from the actuator, including plug/ socket connector.
Connecting cables on request.
Recommended for high ambient temperatures, difficult access or in case of heavy
vibrations during service.
EMERGENCY STOP button
8)
The control voltage of the reversing contactors is interrupted by operating the
EMERGENCY STOP button
Programming software COM-AC incl. interface cable
Other information
EU Directives Electromagnetic Compatibility (EMC): (89/336/EEC)
Low Voltage Directive: (73/23/EEC)
Machinery Directive: (98/37/EC)
Reference documents: Product description “Actuator controls AUMATIC AC”
Dimension sheets Multi-turn actuators/ part-turn actuators “with integral controls AUMATIC
AC”
Baud rate (kbit/s) Max. cable length
(segment length)
without repeater
Possible cable length
with repeater
(total network cable length)
9,6
19,2
45,45
93,75
187,5
500
1.500
1.200 m
1.200 m
1.200 m
1.200 m
1.000 m
400 m
200 m
approx. 10 km
approx. 10 km
approx. 10 km
approx. 10 km
approx. 10 km
approx. 4 km
approx. 2 km
