AUMA Aumatic AC 01.1 Operation Instructions

Actuator controls AUMATIC AC 01.1 / ACExC 01.1
Operation instructions Profibus DP
9
Electrical connections Standard: AUMA plug/socket connector with screw type connection
Threads for cable glands:
M-threads: 2 x M 25 x 1.5 / 4 x M 20 x 1.5
Pg-threads: 2 x Pg 21 / 4 x Pg 13,5
NPT-threads: 1 x 1" NPT / 3 x ¾" NPT
Options: G-threads: 1 x G ¾" / 4 x G ½
Special threads, other than standard mentioned above, possible
Gold-plated control plug (pins and sockets)
Parking frame for wall mounting of the disconnected plug
Protection cover for plug compartment (when plug is removed)
Overvoltage protection (option) Protection of the actuator and control electronics against overvoltages of up to 4 kV (not
available for component redundancy)
Wiring diagram (basic version) ACP 11F1-2P0—S000 KMS TP102/001
Further options for Non-intrusive version with MWG in the actuator
Setting of limit and torque switching via local controls
Electronic timer Start and end of stepping mode as well as ON and OFF time (1 up to 300 seconds) can be
programmed individually for the directions OPEN and CLOSE.
Intermediate positions Any 8 intermediate positions between 0 and 100 %
Reaction and signal behaviour programmable
Further options for version with potentiometer or RWG in the actuator
Electronic timer Start and end of stepping mode as well as ON and OFF time (1 up to 300 seconds) can be
programmed individually for the directions OPEN and CLOSE.
Intermediate positions Any 8 intermediate positions between 0 and 100 %
Reaction and signal behaviour programmable
Settings/programming of the Profibus DP interface
Setting of the baud rate Automatic baud rate recognition
Setting of the Profibus DP
interface
The setting of the Profibus DP address is made via the display of the AUMATIC
Configurable process
representation via GSD file
For an optimal adaptation to the process control system, 4 different process representations
are available.
Additionally the contents of four signal bytes are freely programmable.
Commands and signals of the Profibus DP interface
Process representation output
(command signals)
OPEN, STOP, CLOSE, nominal position value
4)
, RESET
Process representation input
(feedback)
End position OPEN, CLOSED
Actual position value
4)
Actual torque value
5)
Selector switch in position LOCAL/ REMOTE
Running indication
4)
(directional)
Torque switch OPEN, CLOSED
Limit switch OPEN, CLOSED
Manual operation by handwheel
4)
or local controls
Analogue (2) and digital (4) customer inputs
Communication channel A or B (redundant channel) active
Process representation input
(fault signals)
Motor protection tripped
Torque switch tripped in mid-travel
One phase missing
Loss of the analogue customer inputs
Behaviour on loss of
communication
The behaviour of the actuator is programmable:
- stop in current position
- move to end position OPEN or CLOSED
- move to any intermediate position
4)
General data Profibus DP
Communication protocol Profibus DP according to EN 50 170-2, DIN 19 245
Network topology Linear (BUS) structure. With repeaters tree structures can also be realised. Coupling and
uncoupling of devices during operation without affecting other devices is possible.
Transmission medium twisted, screened copper cable according to EN 50 170
Profibus DP interface EIA-485 (RS485)
4) Requires position transmitter in the actuator
5) Requires magnetic limit and torque transmitter (MWG) in actuator
