Assembly instructions
Square head for pit application
Mounting and operation
Y008.832/003/en Issue 1.22 Page 3/3
Change-over force and max. axial force in power tool operation approx. [N]
Type SA... 07.2 SA... 07.6 SA... 10.2 SA... 14.2 SA... 14.6 SA... 16.2
Change-over force [approx.] 130 130 130 140 140 140
Max. axial force in power tool
operation
250 250 250 250 250 250
Standard: Maximum permissible input torque at square head approx. [Nm]
Type SA... 07.2 SA... 07.6 SA... 10.2 SA... 14.2 SA... 14.6 SA... 16.2
Input torque 16 26 60 125 250 500
Option for reduction: Input torque at square head at maximum output torque approx. [Nm]
Output speed [rpm]
SA... 07.2 SA... 07.6 SA... 10.2 SA... 14.2 SA... 14.6 SA... 16.2
50 Hz 60 Hz
4 4.8 2 3 7 14 28 56
5.6 6.7 2 5 9 19 38 76
8 9.6 2 3 7 14 28 56
11 13 2 5 9 19 38 76
16 19 2 3 7 14 28 56
22 26 2 5 9 19 38 76
32 38 2 3 7 14 28 56
45 54 2 5 9 19 38 76
63 75 2 3 7 14 28 56
90 108 2 5 9 19 38 76
125 150 2 4 9 19 37 59
180 216 3 5 10 20 40 81
Option for reduction: Maximum permissible input torque at square head approx. [Nm]
Type SA... 07.2 SA... 07.6 SA... 10.2 SA... 14.2 SA... 14.6 SA... 16.2
Input torque 4 7 15 31 63 125
