AUMA SAV 07.2 Manual

NOTICE for use!
This document is only valid with the latest operation instructions attached to the device, the attached manual,
the attached declaration of incorporation as well as the respectively pertaining technical and electrical data sheets.
They are understood as reference documents.
Purpose of the document:
The present documents informs about the actions required for using the device in safety-related systems in
accordance with IEC 61508 or IEC 61511.
Reference documents:
●
exida report no. AUMA 10-12-035 R005E
●
Operation instructions (Assembly, operation, commissioning) for actuator
●
Manual (Operation and setting) actuator controls AC 01.2/ACExC 01.2
●
Manual (Operation and setting) actuator controls ACV 01.2/ACVExC 01.2
●
Manual (Device integration Fieldbus) AC 01.2/ACExC 01.2 / ACV 01.2/ACVExC 01.2
Reference documents are available on the Internet at: http://www.auma.com.
Table of contents Page
41. Terminology............................................................................................................................
41.1. Abbreviations and concepts
62. Application and validity.........................................................................................................
62.1. Range of application
62.2. Standards
62.3. Valid device types
73. Architecture, configuration and applications......................................................................
73.1. Architecture (actuator sizing)
73.2. Configuration (setting)
73.3. Protection against uncontrolled operation (self-locking/brake)
83.4. Operation mode (low/high demand mode)
83.5. Further notes and indications on architecture
93.6. Applications (environmental conditions)
104. Safety instrumented systems and safety functions...........................................................
115. Installation, commissioning and operation.........................................................................
115.1. Installation
115.2. Commissioning
115.3. Operation
115.4. Lifetime
125.5. Decommissioning
136. Tests and maintenance..........................................................................................................
136.1. Safety equipment: check
136.2. Proof test (verification of safe actuator function)
136.2.1. Preliminary tests
136.2.2. Review and validation of the “Safe end position signal” safety function
146.2.3. Checking the collective fault signal
146.3. Partial Valve Stroke Test (PVST)
146.4. Maintenance
2
Multi-turn actuators
Table of contents SA .2 with AC(V) 01.2/AC(V)ExC 01.2
