Data Matrix code
When registered as authorised user
, you ma
y use our
A
UMA Assistant App
to scan
the Data Matrix code and directly access the order-related product documents without
having to enter order n
umber or ser
ial number
.
Figure 8:
Link to A
UMA Assistant App:
F
or fur
ther Ser
vice & Suppor
t, Software/Apps/...
ref
er to www
.auma.com
12
SQ 05.2
–
SQ 14.2/SQR 05.2
–
SQR 14.2 Control unit:
electronic (MWG)
Name plate
A
C 01.2 Non-Intrusive
11
13
Table of Contents
Table of Contents
2
Safety Instructions
5
Prerequisites for the Safe Handling of the Product
5
Range of Application
5
Warnings and Notes
6
References and Symbols
6
Short Description
7
Name Plate
9
Transport and Storage
13
Transport
13
Storage
14
Assembly
16
Mounting Position
16
Handwheel Fitting
16
Mount Actuator to Valve
16
Overview on Coupling Variants
17
Mount Actuator (with Coupling)
17
Mounting Positions of Local Controls
20
Mounting Positions: Modify
20
Electrical Connection
21
Basic Information
21
S/SH Electrical Connection (AUMA Plug/Socket Connector)
23
Terminal Compartment : Open
24
Cable Connection
25
Terminal Compartment : Close
26
Accessories for Electrical Connection
27
Actuator Controls on Wall Bracket
27
Parking Frame
28
DS Intermediate Frame for Double Sealing
28
External Earth Connection
29
Operation
30
Manual Operation
30
Manual Valve Operation
30
Motor Operation
30
Operating the Actuator from Local Controls
30
Actuator Operation from Remote
31
Menu Navigation Via Push Buttons (for Settings and Indications)
32
Menu Layout and Navigation
33
User Level, Password
34
Password Entry
34
Password Change
35
Timeout for Incorrect Password Entry
35
Language in the Display
36
Language Change
36
Indications
37
Indications During Commissioning
37
Indications in the Display
37
Feedback Signals from Actuator and Valve
38
Status Indications According to AUMA Classification
40
Status Indications According to NAMUR Recommendation
41
Indication Lights of Local Controls
43
Mechanical Position Indication (Self-Adjusting)
43
Mechanical Position Indication Via Indicator Mark (Not Self-Adjusting)
44
Signals (Output Signals)
45
Status Signals Via Output Contacts (Digital Outputs)
45
Assignment of Outputs
45
Coding the Outputs
45
Analogue Signals (Analogue Outputs)
45
Commissioning (Basic Settings)
46
End Stops in Part-Turn Actuator
46
Set End Stop CLOSED
47
Set End Stop OPEN
47
Type of Seating: Set
48
Torque Switching: Set
49
Limit Switching: Set
51
Test Run
52
Direction of Rotation at Mechanical Position Indicator: Check
53
Limit Switching: Check
53
Commissioning (Settings in the Actuator)
55
Switch Compartment: Open/Close
56
Mechanical Position Indicator (Self-Adjusting)
56
Mechanical Position Indicator: Set
56
Gear Stage of the Reduction Gearing: Test/Set
57
Mechanical Position Indication Via Indicator Mark (Not Self-Adjusting)
58
Mechanical Position Indicator: Set
59
Gear Stage of the Reduction Gearing: Test/Set
59
Corrective Action
61
Faults During Commissioning
61
Fault Indications and Warning Indications
61
Fuses
65
Fuses Within the Actuator Controls
65
Fuse Replacement
65
Replace Fuses
65
Test/Replace Fuses
66
Motor Protection (Thermal Monitoring)
66
Servicing and Maintenance
68
Preventive Measures for Servicing and Safe Operation
68
Maintenance
68
Disposal and Recycling
68
Technical Data
70
Technical Data Part-Turn Actuator
70
Technical Data Actuator Controls
72
Tightening Torques for Screws
77
Spare Parts
78
Part-Turn Actuators SQ
78
Sq 14.2/Sqr 05.2
78
AC 01.2 Actuator Controls with S Electrical Connection
80
Index
84
