Aura Roboclean Splus 114K - Body Assembly

17
18
19
1 TouchscreenControlPanel
2 On/OffButton
3 Handle
4 PowerNozzleOutletCover
5 PowerNozzlePowerOutlet
6 SuctionNozzlePort
7 PowerCord
8 RearPanelCover
9 IonOutletChannel
10 Separator
11SeparatorNut
12SeparatorCleaningBrush
13 Pollen Filter
14 Safety Switch Mechanism
15LockingLatches
16 BasinLeds
17 Dolly
18CleanWaterBasin
19DirtyWaterBasin
BODYASSEMBLY
9
