Auriol Z29962C - Mounting the Weather Station; Mounting the External Sensor

15 GB/IE
Q
Weather station
j Mark the position of the hole (ø approx. 7 mm)
on the wall.
j Drill the hole with an electric drill.
j Insert the dowel
23
into the drilled hole.
j Using a crosshead screwdriver, screw the
screw
24
into the dowel
23
.
j Hang the weather station by placing the hanger
20
on the screw
24
.
Q
External sensor
j Mark the position of the hole (ø approx. 5 mm)
on the wall.
j Drill the hole with an electric drill.
j Insert the dowel
28
into the drilled hole.
j Using a crosshead screwdriver, screw the
screw
29
into the dowel
28
.
j Hang the external sensor by placing the
hanger
26
on the screw
29
.
Note: Choose a sheltered position for the external
sensor, not directly near the weather station (e.g.
separated by a wall). Ensure that the external sensor
does not come into contact with water or direct
sunlight. Electronic devices may adversely affect
the wireless signal reception.
Q
Setting up the weather station
j Place the stand
22
on the underside of the
weather station.
