STEP 7- Inst
all Drip Pan, Charcoal Grate & Cooking Grid
(ITEM 23) Charcoal Grate
(ITEM 24) Cooking Grid
12
· Slide Drip Pan back into Grill Body. Make sure the Drip Pan is pushed all the way in.
· Hang Charcoal Grate inside Grill Body by hooking the handles inside the two (2) elongated slots
on each side of the Grill Body.
· Lay the Cooking Grids on the front and rear Body shoulders above the Charcoal Holder.
(ITEM 22) Drip Pan
Install Grids on
Front and Rear
Shoulder of Body
Slide Drip Pan
under Body
Hook Handles
into slots
To Next Page
