Austroflamm Integra II - Main Control Board Details; Control Board Component Identification

Diagram A
8
MAIN CONTROL BOARD
4
A Bus 1
B Bus 2
C Bus 3
a Fine-wire fuse
b Capacitor
1. HAL-RG-fan
2. Control board
3. Tele/Pellet-Control
4. Air sensor
5. UTB
6. OTB
7. FKY 1
8. FKY 2
9. Alarm
I. Network 230VAC 50Hz
II. RG-fan
III Cross flow fan
IV Ignition element
V Auger motor
VI Circulating pump
VII Reserve
MAIN CONTROL BOARD
1
2
3
4
5
6
7
8
9
VII VI
V
IV
III
II
I
yellow/green
blue
brown
PE
N
L
a
b
PE yellow/green
A
BC
Fig. 6
Hall IC combustion motor
Low limit sensor
Open
Open
Open
User board
Thermostate
High limit sensor
Open
110V power cord
Combustion motor
Convection fan
