9 Technical Data
9.1 Ben
Nominal heat output (NHO)
5 kW / 6.7 kW
Partial load heat output
1.5 kW / 2 kW
Room heating capacity
48 – 124 m³ / 65 – 165 m³
Efficiency
92% / 90%
CO content at NHO
92.1 mg/Nm³ / 72.7 mg/Nm³
CO content at partial load (PL)
190.4 mg/Nm³ / 119.9 mg/Nm³
Flue gas temperature at NHO
135 °C / 176 °C
Flue gas temperature at PL
72 °C / 97 °C
Flue gas mass flow at NHO
4.28 g/s / 5.2 g/s
Flue gas mass flow at PL
3.38 g/s / 3.64 g/s
Minimum discharge pressure at NHO
12 Pa /13 Pa
Minimum discharge pressure at PL
10 Pa / 11 Pa
Minimum draught for chimney calculation
3 Pa
Filling capacity of hopper
24 kg / 38 l
Min./max. pellet consumption
0.4 – 1.2 kg/h / 0.5 – 1.7 kg/h
Min./max. autonomy
approx. 20 - 60 hrs / approx. 15 -
50 hrs
Air inlet nozzle Ø
80 mm
Flue gas outlet Ø
80 mm
Electrical power consumption when switching on
325 W
Electrical power consumption during operation
13.0 W / 25.6 W
Voltage / current frequency
230 V / 50 Hz
Dimensions
H x W x D 1000 x 500 x 531 mm
Weight
154 kg
Minimum distance
at the side 100 mm
at the rear 100 mm
at the front 800 mm
Temperature limits
0 - 40°C
Relative humidity
non-condensing
