english 29
9.4 Ruby
Nominal heat output (NHO)
8.1 kW
Partial load heat output
2.3 kW
Room heating capacity
110 - 290 m³
Efficiency
91.8%
CO content at NHO
11 mg/Nm³
CO content at partial load (PL)
178 mg/Nm³
Flue gas temperature at NHO
158 °C
Flue gas temperature at PL
75.9 °C
Flue gas mass flow at NHO
4.7 g/s
Flue gas mass flow at PL
2.9 g/s
Minimum discharge pressure at NHO
12 Pa
Minimum discharge pressure at PL
10 Pa
Minimum draught for chimney calculation 3 Pa
Filling capacity of hopper
25 kg / 39 l
Min./max. pellet consumption
0.51 – 1.79 kg/h
Min./max. autonomy
approx.14 - 49 hrs
Air inlet nozzle Ø
60 mm
Flue gas outlet Ø
80 mm
Electrical power consumption when switching on
325 W
Electrical power consumption during operation
approx. 25 W
Voltage / current frequency
230 V / 50 Hz
Dimensions H x W x D 1120 x 690 x 440 mm
Weight
211 kg
Minimum distance at the side 100 mm
at the rear 100 mm
at the front 800 mm
Temperature limits
0 - 40°C
Relative humidity
non-condensing
