installation and operation manual
2016-08-26 13
4.4 Mounting procedure
Step 1 — Mount the wall bracket onto the mounting wall with appropriate screws plugs
Step 2 — Lower the inverter onto the bracket
290 ± 2 mm
104 ± 2 mm
