6.5 Advanced info
WARNING! Access to this section of the menu is for Autarco qualified and accredited
technicians only. Unauthorized access will void the product and system warranty.
The default password is “0010". Press “DOWN” to move the cursor, press “UP” to select the number. After you
enter the correct password, you will be able to access the information as shown in the table below.
Press the UP/DOWN keys to scroll through the information. Press ENTER key to enter a submenu. Press ESC key
to go back to the main menu.
Alarm Messages
Scroll through the last ten alarm messages for trouble shooting purposes.
Press UP/DOWN keys to cycle through alarm messages
Press ESC key to return
Temperature
The screen shows the temperature of the inverter in degrees Celcius.
Standard NO.
The screen shows the current grid standard
Version
The screen shows the operating software version of the inverter
Communication data
The screen shows information interpretable to qualified technicians only
6.6 Advanced Settings
WARNING! Access to this section of the menu is for Autarco qualified and accredited
technicians only. Unauthorized access will void the product and system warranty.
Refer to 6.5 for the password to access this menu.
Select grid standard
WARNING! Set GRID OFF (see below) before changing this
setting.
Press UP/DOWN keys to cycle through available standards
 AS4777
 VDE0126
 UL1741
 G83
 User defined
Press ENTER key to save the setting
Press ESC key to cancel and return
When selecting User defined the following upper and lower values have to
be set for voltage and frequency:
OV-V: 240-270V
UV-V: 180-210V
