Note: Lighting or temperature may affect the brightness of the scan tool screen.
Use the backlight to adjust the screen if needed.
Audible Beep
When pressing any display on the screen, the action is acknowledged by an audible beep.
You can mute the beep as follows:
1. Highlight the Setup/ Help from the main menu, then select the Beep. The dialog box
shows.
2. Select the Close to mute the Beep.
3. Click OK to save the change, or click Cancel to exit without save changes.
Note: Select Open to undo the mute.
Calibrating Touch Screen
This calibration is already done by manufacturer. If you want to calibrate the touch screen
again, refer to the following instruction to calibrate.
1. Highlight the Setup/ Help button and select the Touch.
2. A new platform shows, carefully press and briefly hold stylus on the center of the
target, repeat as the target moves around the screen.
3. When the process ended, press the button in the upper right-hand corner to save. If
you do not want to save the change, simply wait without any button pressed for 30
seconds.
Important: Use the supplied stylus or plastic-tipped pens for touch screen display. Do
not use pencil, pen or any sharp object on touch screen display.
Remote desk
The Remote Desk function allows you to view the screen of your MaxiDAS 708 on a
computer, also makes controlling your MaxiDAS 708 from a computer possible.
To use Remote Desk on both MaxiDAS 708 and a computer, do the followings:
1. Install the client software of VNC Viewer correctly, which is provided in MaxiDAS 708
CD.
2. Click on
icon in Setup/Help from the main menu. A window pops up.
