……………… .Live Data………… ……..
1/3
►View Data
Record Data ?
Playback Data
Viewing Complete Data Set
4) To view complete set of data, use UP/DOWN scroll button to
select Complete Data Set from View Data menu and press
ENTER button.
…………………View Data…… ……… …..
1/3
► Complete Data Set
Custom Data Set
Unit of Measure ?
5) View live PIDs on the screen. Use UP/DOWN scroll button for
more PIDs if an
or arrow appears on the screen.
Live Data…… ……. …
6
DTC_CNT 6
FUELSYS1 OL
FUELSYS2 N/A ?
LOAD_PCT (%) 0.0 G
ETC(℃) -40
32
z The number “x” to the right of the screen indicates sequence
of highlighted item.
z If you want to view full name of the highlighted PID, press
Help button.
► SHRTFT1 (%) 0.0
