18
Figure 5.8
TABLE 5-1 POSSIBLE RESULTS FOR TESTING
TPMS sensor is successfully activated and decoded.
The tool displays the sensor information.
If the search period expires and no sensor activation
or decode, it may be wrong sensor fitting or non-
functioning sensor. In this case, repeat test to confirm
the TPMS failure.
A TPMS sensor is activated and decoded, but does
not match the protocol for the Make, Model or Year of
the vehicle. Verify the Make, Model or Year and the
sensor part number.
A sensor with a duplicate ID has been read. Clear
data and re-read again.
