16 13
You may get this
message if the battery
tests “low”. Answer by
touching the red “NO”,
or green “YES” button.
If you are unsure,
choose “NO”.
If a battery has tested
good, however the
tester detects normal
wear. Recommend
retesting battery in
3 months. months,
as this battery may
fail under extreme
circumstances, and
is nearing the end of
its life.
The battery tested
good, however
is low on charge,
you will receive
this message.
Recommend
charging battery.
This screen will
appear if “NO” was
chosen above.
Charge the battery
and retest.
This screen will
appear if the
battery is bad, or if
“YES” was chosen
above. Replace
the battery, as the
battery tested bad,
or did not properly
accept a charge.
If the battery
tested good,
this screen will
appear. No further
charging, or testing
of the battery is
required at this
time.
BATTERY TEST
2
FULL SYSTEM TEST
Touch the green
"Full System
Test" button.
Follow battery
test procedure,
the same as
shown in the
Battery Test
section.
If the battery is
failed, or too low of
charge, you will not
be able to proceed
to the starting test
until a charged, or
replacement battery
is installed.
When the
Battery Test
passes as a
Good Battery,
this screen will
appear. Touch
the green
“Proceed to
Starting Test”
button.
There are a few points to consider in testing a starting system on a diesel
engine.TheBVA-360/360Pisdesignedtorecognizeanysignicantamountof
draw; this includes glow plugs in small diesel engines.
• Make sure you start the engine quickly. The engine should be warm.
• Turn the ignition on and allow the glow plugs to heat up and click off before
you run the Starting Test.
STARTING CURRENT DRAW AND DIESEL ENGINES
Proceed to
Page 17
5
To Next Page
