Remove the shaded area
TOP
109 mm (4.3 in)
Control unit - flush mount template
114 mm (4.5 in)
4 holes
6 mm (0.25 in)
diameter
D4437-3
81131_6.book Page 123 Wednesday, August 22, 2001 2:26 PM
