Spoke clamp
Spoke diameters
Wheel drive - spoke clamp template
Center
of wheel
Spoke clamp
insert
D5410-1
135 mm (5.3 in)
16 mm (5/8 in)12 mm (1/2 in)
81131_6.book Page 125 Wednesday, August 22, 2001 2:26 PM
