AUTOHELM ST4000+ User Manual

viii ST4000+ Wheel & Tiller Autopilots: Owner’s Handbook
7.2 Dealer setup ..........................................................................106
Calibration lock (CAL LOCK) ............................................. 108
Pilot type (4000 WHL/TILL) ............................................... 108
Rudder gain (RUDD GAIN) ................................................. 108
Response level (RESPONSE) .............................................. 108
Turn limit (TURN RATE) ..................................................... 108
Rudder alignment (ALIGN RUD) ........................................ 108
Rudder limit (RUD LIMIT) .................................................. 109
Off course alarm (OFF COURSE) ........................................109
AutoTack angle (AUTOTACK) ........................................... 109
AutoTrim (AUTOTRIM) ..................................................... 110
Drive type (DRIVE TYP) ..................................................... 110
Magnetic variation (VARIATION) ....................................... 110
AutoAdapt (AUTOADAPT) .................................................111
Latitude (LATITUDE) ...........................................................111
Rudder damping (RUDD DAMP) ........................................ 112
Cruise speed (CRUISE SP) .................................................. 112
Specifications .................................................................... 113
Glossary .............................................................................. 115
Index ................................................................................... 117
81131_6.book Page viii Wednesday, August 22, 2001 2:26 PM

AUTOHELM ST4000+ Specifications

General

Type	Autopilot
Drive Type	Wheel Drive
Control Unit	ST4000+ Control Head
Power Supply	12 V DC
Interface	SeaTalk
Display Type	LCD
Control	Push-button
Voltage	12 V
Compass	Fluxgate Compass
Course Accuracy	±1°
Compass Safe Distance	1 meter
