2007
Directed Electronics
11
System Features Menus
Note: Factory default settings are shown in BOLD.
Note: When changing features that have more then 2 options
in the right column, you will use the unlock button on the
remote to toggle through these options. The horn will honk the
number of times to confirm the feature setting.
Example:Feature 3 has 4 settings. If 40ms was the desired
setting, the horn will chirp 4 times.
Note: If feature 1 is selected for Passive or Auto rearm, feature
6 is not recommended for Passive locking. The system can
possibly lock the end user out of their vehicle.
Feature Descriptions
The features of the system are described below.
Feature One-chirp/LED ON Setting Two-chirp/LED OFF Setting
Number (chirp# in ( ) for multiple options)
1 Active arming Passive(2)/Auto rearm setting(3)
2 Horn honk ON OFF(2)/OEM style(3)
3 Horn output duration 50ms 20ms(2)/30ms(3)/40ms(4)
4 Ignition lock OFF Ignition lock ON
5 Ignition unlock OFF Ignition unlock ON
6 Active locking Passive locking
7 Ignition-controlled domelight ON Ignition-controlled domelight OFF
8 Door lock pulse duration 0.8s Door lock pulse duration
3.5s(2)/0.4s(3)
9 Double pulse unlock OFF Double pulse unlock ON
10 Double pulse lock OFF Double pulse lock ON
11 Security features OFF Security features ON
12 Code Hopping ON Code Hopping OFF
13 2nd unlock ouput OFF 2nd unlock ouput ON
14 Comfort closure OFF Comfort closure ON (CC1(2) and
CC2(3))
15 Aux relay Domelight supervision Aux channel 2
