2007
Directed Electronics
13
11 SECURITY FEATURES: When selected
OOFFFF
, the (-) ground-when-armed and ignition sense
trigger will not be active upon locking the vehicle. When selected ON, (-) ground-when-armed
output will be active and can be used to operate a starter kill. The unit will also trigger a panic
sequence if the ignition is turned on before unlocking/disarming the system.
12 CODE HOPPING
OONN
/OFF: The system uses a mathematical formula to change its code each
time the transmitter and receiver communicate. This makes the group of bits or "word" from the
transmitter very long. The longer the word is, the easier it is to block its transmission to the unit.
Disabling the Code Hopping
®
feature lets the receiver ignore the Code Hopping
®
part of the trans-
mitted word. As a result, the unit may have better range with Code Hopping
®
off.
13 2ND UNLOCK OUTPUT
OOFFFF
/ON: When selected OFF, the H1/2 blue wire has no function.
This feature is defaulted off to allow the user to be able to press unlock on the (4-Button) to unlock
the car no matter what state the vehicle in. When using a (3-Button) single lock/unlock button it
will just toggle back and forth between lock and unlock. When selected ON, pressing unlock twice
on the remote will output a negative pulse on the H 1/2 blue wire.
14 Comfort closure OFF/CC1/CC2: The system can be programmed to close the windows when
the system is armed. When CC1 is selected, a 20-second output starts 200ms after the last lock
pulse. When CC2 is selected, a 20-second output starts immediately after the lock pulse. NOTE:
CC2 was designed for some vehicles that may panic the factory alarm when set in the CC1 setting.
15 Aux relay control (DOMELIGHT SUPERVISION/Aux Channel 2): When selected to
domelight supervision and feature 7 is turned on, the dome light will turn on for 30 seconds every
time the ignition is turned off and upon unlock/disarm. When selected to Aux Channel 2, the
onboard domelight supervision relay is converted into a high current Aux channel 2 and in return
the red/white H 1/18 wire is converted to a 200mA (-) domelight supervision output.
Transmitter/Receiver Learn Routine
The system comes with two transmitters that have been taught to the receiver. The receiver can store
up to four different transmitter codes in memory. Use the following learn routine to add trans-
mitters to the system or to change button assignments if desired.
1.
KKeeyy..
Turn the key to the ON position.
