Automated Logic G4106 User Manual

12
Rev (29-AUG-97) • Module Driver v4.7
© 1995-97 Automated Logic Corporation
Module Driver
Parameter Page
Function Block Type: G6N (Module G4106)
Name CM 03 G4106 Line 1 GCM 1 CM 3 FB 15 Flags —
ID ID14 Tele NB All Options Y Type 61 Ver 1
Alarms Enabled ———— Text 1 0 0 0 0 0 0 11
Messages Enabled ———— Text 0 0 0 0 0 4 0 0
This is the translation table for the custom gain of 15.00.
Is input specified in voltage? NO .
0 x10 Ohms = 296.0
143 x10 Ohms = 168.8
334 x10 Ohms = 125.6
599 x10 Ohms = 98.69
779 x10 Ohms = 87.44
1000 x10 Ohms = 77.00
1285 x10 Ohms = 66.88
1666 x10 Ohms = 56.75
3007 x10 Ohms = 34.94
6995 x10 Ohms = 6.38
32767x10 Ohms = -60.2
This is the translation table for the custom gain of 15.06.
Is input specified in voltage? YES.
0 Millivolts = 0.00
500 Millivolts = 50.00
1000 Millivolts = 100.0
1500 Millivolts = 150.0
2000 Millivolts = 200.0
2500 Millivolts = 250.0
3000 Millivolts = 300.0
3500 Millivolts = 350.0
4000 Millivolts = 400.0
4500 Millivolts = 450.0
5000 Millivolts = 500.0
Mask Outside Air Invalid condition? NO
This module should display old-style FB trends NO
Enable debug screen NO (for Tech Support use)
Status Page
Function Block Type: G6N (Module G4106)
Name CM 03 G4106 Line 1 GCM 1 CM 3 FB 15 Flags —
ID ID14 Tele NB All Options Y Type 0 Ver 0
Active Alarms ———— Active Messages ———— Status-Code 0
Real Module Address 0
This module contains the following function blocks:
Trending Information:
FB Exp Chan Trending Interval Samples
— —— —— ———— ———— ———
