ATS Series Installation Manual2
Table of Contents
1. Installation Safety Warnings! 3
2. Before you Begin 4
3. Tools Required 4
4. Kit Contents 5
5. Position 5
6. Fit the Opener 6
7. Bracket Position 6
7.1 Wall Bracket Position: 6
7.2 Mounting The Wall Bracket: 6
7.3 Attach The Rail To The Wall Bracket 6
8. Perforated Angle 7
9. Mounting Brackets and Arms 7
9.1 Mounting The Door Bracket: 7
9.2 Attaching the Arms 7
10. Safety Beam Kit (ATS-3 Only) 8
10.1 Assemble the Mounting Bracket 8
10.2 Mounting the Bracket 8
10.3 Connect the Safety Beams 8
11. Specifications 9
12. Setting Limits 10
12.1 Set Limit Positions and adjust drive speed: 10
12.2 Clearing the Door Limit Positions 11
12.3 Re-profiling the Door 11
12.4 Controller memory reset 11
13. Safety Testing 12
13.1 Test the Close Cycle 12
13.2 Testing the Open Cycle 12
13.3 Test the Manual Door Operation 12
14. Auto-Close 13
15. Coding a Transmitter 14
15.1 Storing the Transmitter Code 14
15.2 Installation of the Wall Mounted Transmitter 14
15.5 Remotely Coding Transmitters 14
15.3 Erasing All Transmitter Codes 14
15.4 Vacation Mode 14
16. Smart Phone Control (ATS-3 Only) 15
Installation Instructions
Home Owner Instructions
WARNING! IMPORTANT SAFETY INSTRUCTIONS
FOLLOW ALL INSTRUCTIONS SINCE INCORRECT INSTALLATION CAN LEAD TO SEVERE INJURY.
• before installing the drive, remove all unnecessary ropes or chains and disable any equipment, such as locks, not needed for
powered operation;
• before installing the drive, check that the door is in good mechanical condition, correctly balanced and opens and closes
properly;
• install the actuating member for the manual release at a height less than 1,8 m;
• install any fixed control at a height of at least 1,5 m and within sight of the door but away from moving parts;
• permanently fix the labels warning against entrapment in a prominent place or near any fixed controls;
• permanently fix the label concerning the manual release adjacent to its actuating member;
• after installation, ensure that the mechanism is properly adjusted and that the drive reverses when the door contacts a 40
mm high object placed on the floor.
• necessary information for the safe handling of a drive weighing more than 20 kg. This information shall describe how to use
the handling means, such as hooks and ropes;
• the drive must not be used with a door incorporating a wicket door (unless the drive cannot be operated with the wicket door
open);
• after installation, ensure that parts of the door do not extend over public footpaths or roads.
• vertical doors and gates need an anti-drop feature or device;
• information if a hazardous part of the drive is intended to be installed at a height of at least 2.5 m above floor level or other
access level;
• except for horizontally moving pedestrian doors, ensure that entrapment due to the opening movement of the driven part
is avoided
17. Home Owner Safety Warnings! 16
18. Opener Safety & Security 17
18.1 Your Door CAN NOT be used when: 17
18.2 Your Door CAN be used when: 17
18.3 To Disengage the Opener: 17
18.4 To Re-Engage the Opener: 17
19. Operating your Opener 17
20. User Operating Controls 18
21. Troubleshooting 19
22. After Installation Care 21
22.2 Battery Replacement 22
22.3 Battery Disposal 22
22.4 Warranty 22
23. Appendix 23
A - Status Indication during Operating Mode. 23
B - Adjustment Mode Instructions 24
C - Adjusting Force Margins 24
D - Battery Functions 25
E - Setting limits via Transmitter 25
F - Setting the PET Mode position 26
G - Setting up Tilt Door 26
