ATS Series Installation Manual9
11. Specifications
Technical Specifications SYNCRO
ATS-3
TEMPO
ATS-2
Rated voltage range: 230V - 240Va.c. 230V - 240Va.c.
Rated frequency: 50Hz / 60Hz 50Hz / 60Hz
Rated power input: 165W 165W
Door opening:
Maximum Door Area:
Maximum Door Weight:
Door must be well balanced and able to
be operated by hand, as per warranty
conditions and AS/NZS 4505:2012
18m
2
236kg*
18m
2
200kg*
Minimum headroom 57mm 57mm
Rated Operating Time 4 mins 4 mins
Rated Temp +5
o
C to +40
o
C +5
o
C to +40
o
C
Short Term Peak force: 1100N 1100N
Rated load 400N 400N
Nominal force 200N (20kg) 200N (20kg)
Receiver type Multi-frequency UHF FM
(433.47, 433.92 & 434.37MHz)
Multi-frequency UHF FM
(433.47, 433.92 & 434.37MHz)
Receiver code storage capacity 64 X 4-button Transmitters 64 X 4-button Transmitters
Transmitter battery CR2032 (3 Volts) CR2032 (3 Volts)
Main light LED (Light Emitting Diodes) LED (Light Emitting Diodes)
Network connectivity Network ready,
Smart hub already installed
Network compatible,
(requires optional Smart Phone Control Kit)
* Gross door weight, including all fittings
Note: Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra pressure on the
door and tracks which may in turn intermittently trigger the safety obstruction detection system.
