Owner Installation Instructions NeoSlider
TM
- Sliding Gate Opener NES-500 / NES-800
Technical Specifications NES-500 NES-800
Input Voltage:
1,
230 - 240 Vac 230 - 240 Vac
Mains frequency: 50 Hz 50 Hz
Maximum Input Power: 200 W 200 W
Maximum pulling force: 280N 700N
Maximum gate opening:
2,
Width:
Weight:
10m
Up to 500kg
10m
Up to 800kg
Receiver type: TrioCode™128 TrioCode™128
Receiver code storage capacity: 30 x 4 Button Transmitter Codes 30 x 4 Button Transmitter Codes
Transmitter frequency: 433.47, 433.92, 434.37 MHz 433.47, 433.92, 434.37 MHz
Coding type: Hopping Code Hopping Code
No. of code combinations: Over 100 billion random codes Over 100 billion random codes
Code generation: Non-linear encryption algorithm Non-linear encryption algorithm
Transmitter battery: CR2032 CR2032
NOTE:
1. Measurements made at 240Vac.
2. The maximum gate size that the NeoSlider™ NES-500 can be installed on is 10m wide and 500kg and
the NeoSlider™ NES-800 can be installed on is 10m wide and 800kg. The gate must be well balanced.
A person should be able to move the gate manually with very little effort (15kg force max.) in case of an
emergency.
3. Intermittent operations may occur in areas which experience very strong wind gusts. A strong wind puts
extra pressure on the gate and tracks which may in turn trigger the safety obstruction detection system
intermittently.
NOTE: Specifications are subject to change without notice.
17. Specifications
