Owner Installation Instructions NeoSlider
TM
- Sliding Gate Opener NES-500 / NES-800
Parameter Min Max Default Step Unit Menu Section
Menu 1 - Code Transmitter
STORING TRANSMITTERS 0.0 511 1 10.1
Menu 2 - Current Trips
M1 MARGIN
Sets obstruction detection margin for M1
0.0 4.0 0.7 0.1 AMPS 2.1 9.3
SETTLE TIME disable the obstruction detection in the start of
the cycle
0.1 2.0 1.0 0.1 SEC 2.2
Menu 3 - Auto Close
STD AUTO-CLOSE TIME
Sets and enables the standard Auto-Close time
0.0 300.0 0.0 1.0 Sec 3.1 15.1
SAFETY BEAM AUTO-CLOSE TIME Sets and enables the SB
triggered Auto-Close time
0.0 60.0 0.0 1.0 Sec 3.3 15.2
PEDESTRIAN AUTO-CLOSE TIME Sets and enables the
Pedestrian Auto-Close time
0.0 60.0 0.0 1.0 Sec 3.4 15.3
SAFETY BEAM PEDESTRIAN AUTO-CLOSE TIME Sets and
enables the SB Pedestrian Auto-Close time
0.0 60.0 0.0 1.0 Sec 3.6 15.3
AUTO-CLOSE AFTER CLOSE OBSTRUCTION
Enables Auto-Close feature after close obstructions
Off On Off 3.7 15.4
AUTO-CLOSE AFTER OPEN OBSTRUCTION
Enables Auto-Close feature after open obstructions
Off On Off 3.8 15.4
AUTOCLOSE AFTER POWERUP
Enables autoclose feature after powerup
Off On Off 3.9 15.4
Menu 4 - Lock Times
OPEN LOCK TIME Set the time the lock is activated for on
open cycles
0.0 Hold 0.5 0.1 Sec 4.1 16.1
CLOSE LOCK TIME Set the time the lock is activated for on
close cycles
0.0 Hold 0.5 0.1 Sec 4.2 16.1
PRE-OPEN LOCK TIME Time the lock is activated for prior to
opening
0.0 25.5 0.0 0.1 Sec 4.3 16.1
PRE-CLOSE LOCK TIME Time the lock is activated for prior to
closing
0.0 25.5 0.0 0.1 Sec 4.4 16.1
Menu 5 - Light Times
ON AFTER CYCLE LIGHT TIME - Time light remains on for
after a cycle
0 255 60 1 Sec 5.1 16.2
ON BEFORE OPEN CYCLE LIGHT TIME
Minimum time light is activated for prior to opening
0 255 0 1 Sec 5.2 16.2
ON BEFORE CLOSE CYCLE LIGHT TIME
Minimum time light is activated for prior to closing
0 255 0 1 Sec 5.3 16.2
Menu 6 - Motor Settings
OPEN SPEED VOLTS
Voltage applied to motors when opening
12 24 22 1 VOLTS 6.1
CLOSE SPEED VOLTS
Voltage applied to motors when closing
12 24 20 1 VOLTS 6.2
SLOW SPEED VOLTS
Voltage applied to motors when slowing down
6 24 8 1 VOLTS 6.3
SLOW TIME
The time between slow down and end of cycle
0.1 10.0 3.0 0.1 SEC 6.4
OPERATIONAL BUTTONS:
1. Press PREV/NEXT buttons move to Left/Right.
2. Press OPEN/CLOSE buttons to change setting.
3. Press SET button to save changes.
4. Press EXIT to return to MENU without saving changes.
19. Appendix
A - Console Menu Structure
