Select functions: There are 4 modes in CTT, (left to right) timer, counter, tachometer and timer + counter.

Select counter functions: 1-stage counting, 2-stage counting, batch counting, total counting, dual counting.

CntFun sta6e1 sta6e2 batCh total dual

Dual

–add –sub

Select dual mode: Add or Subtract

C–otmd

FnCr kp

Select output modes: CTT offer 11 output modes, among which mode S, T and D are only valid with input modes

Ud_A, Ud_b and Ud_C.

Select counting speed: Maximum 10Kcps; others 5K, 1K, 200, 30 and 1cps.

C–Sped –10k ––5k ––1k –200 ––30

t–out1

Pulse width of output 1: The default output time is 0.02 second. When the parameter is set to 0.00 second, the

output status will be maintained ON. Range = 0.00 to 99.99 seconds.

–––1

–002 –000

t–out2

Pulse width of output 2: This paramter is adjustable according to different output modes selected. If the output mode is C,

the default output time will be 0.02 second. Range = 0.01 to 99.99 seconds.

–002 –000

–point

Set up the position of decimal point: 0 (no decimal point), 1 (one digit after decimal point), 2 (two digits after decimal

point), 3 (three digits after decimal point).

0123

psCale 1000

Set up pre-scale value: 1.000 (default 1:1) Range: 0.001 to 99.999

–pwers

Save the data while switching off the power: When SAVE is selected, the PV will be saved; when CLEAR is selected,

the PV will not be saved.

Clear save

–rtsr

Set up minimum width of reset signal: Default = 20ms; 1ms is also selectable

––20 –––1

inptlC

Select input signal types: NPN and PNP

–npn –pnp

–FunC Cont taCh –mixtime

or or or

or or or or or

or or or or or or

or or

or or or or

or or

or or or or

To enter the page for parameter setting of the counter, press

for the main menu for more than 3 seconds.

After the setup is completed, press

for more than 3 seconds under any of the parameter page you are in and

return to the main menu.

Keypad set up of the parameters for Dual Counting:

Used to convert the displayed PV into engineering unit, such as RPM, inches, millimeters, feet per minute etc. See

Tachometer Examples in Chapter 6
