Mode A (
A
)
When the count present value PV counts up to the count
setting value SV2 both Output 2 will turn ON momentarily
for the time set in the output pulse width parameter (
tout2
).
The count PV will remain at the count SV2 regardless of addi-
tional input signals.
The leading edge of a “reset” input signal at RST1 will turn
Output 2 OFF, reset the count PV to 0 and prohibit an input
signal from incrementing the count PV. The trailing edge of the
“reset” signal at RST1 enables counting to begin.
The “reset” signal minimum pulse width is set by reset pulse
width parameter (
rtSr
).
OUT2
TT
TIMER + COUNTER
Counter Input Mode UP
Counter Output Mode A
RESET
999999
To Next Page
