SOLO Basic Temperature Controller Specifications
Specifications
Input Power Requirements
100 to 240 VAC 50 / 60 Hz
Operation Voltage Range
85 to 264 VAC
Power Consumption
5 VA Max
Control Mode
PID, ON/OFF or Manual
Input Accuracy
TC temperature indication accuracy: ±(0.3% of span + 1 digit) at
25°C ambient after 20 minutes warm up.
Including NIST conformity, cold junction effect, A/D conversion errors
and linearization conformity
RTD temperature indication accuracy: ±(0.2% of span +1 digit)
Vibration Resistance
10 to 55 Hz, 10 m/s
2
for 10 min, each in X, Y and Z directions
Display
2 line x 4 character, 7-segment LED display
PV: 11mm red
SV: 9.2 mm green
Shock Resistance
Max. 300 m/s
2
, 3 times in each 3 axes, 6 directions
Ambient Temperature Range
32°F to 122°F (0°C to 50°C)
Storage Temperature Range
-4°F to 149°F (-20°C to 65°C)
Altitude
2000m or less
Relative Humidity
35% to 80% (non-condensing)
IP Rating
IP66: Complete protection against dust and powerful water jets from
all directions.
(**inside suitable enclosure)
Agency Approvals
UL, CUL, CE (UL file number E311366)
Pollution Degree
Degree 2 - Normally, only non-conductive pollution occurs.
Temporary conductivity caused by condensation is to be expected.
Input Types
• Thermocouple*
K, J, T, E, N, R, S, B, L, U, TXK (Sampling Rate: 100 ms / per scan)
• Platinum RTD
3-wire Pt100, JPt100 (Sampling Rate: 100 ms / per scan)
• Copper, Nickel
RTDs
Cu50, Ni120 (Sampling Rate: 100 ms / per scan)
Control Output Options
• Relay (R)
SPST max. 5A @ 250 VAC resistive load
• Voltage Pulse (V)
DC 12V±15%, output current 40mA Max
• Current (C)
DC 4-20 mA output (sourcing) (Load resistance: Max 600Ω)
Alarm Output Option
(2) SPST relays with shared common, 3A @ 250VAC resistive load
*Note: Use only ungrounded thermocouples.
** No corrosive gases
