Chapter 3: Keypad Operation and Setup Parameters
SOLO Basic Temperature Controller User Manual
3–12
Initial Setting Parameters
Press the
;
button for more than three seconds to access these
parameters.
Inpt
Input Type
This parameter defines the input signal type.
Thermocouple* Type and Temperature Range
Input Temperature Sensor Type
LED
Display
Temperature Range
Thermocouple TXK type
txk
-238 ~ 1472°F (-150 ~ 800°C)
Thermocouple U type
u
-328 ~ 932°F (-200 ~ 500°C)
Thermocouple L type
l
-328 ~ 1562°F (-200 ~ 850°C)
Thermocouple B type
b
212 ~ 3272°F (100 ~ 1800°C)
Thermocouple S type
s
32 ~ 3092°F (0 ~ 1700°C)
Thermocouple R type
r
32 ~ 3092°F (0 ~ 1700°C)
Thermocouple N type
n
-328 ~ 2372°F (-200 ~ 1300°C)
Thermocouple E type
e
32 ~ 1112°F (0 ~ 600°C)
Thermocouple T type
t
-328 ~ 752°F (-200 ~ 400°C)
Thermocouple J type
j
-148 ~ 2192°F (-100 ~ 1200°C)
Thermocouple K type
k
-328 ~ 2372°F (-200 ~ 1300°C)
RTD Type and Temperature Range
Input Temperature Sensor Type LED Display Temperature Range
Platinum (Pt100)
pt
-328 ~ 1562°F (-200 ~ 850°C)
Platinum (JPt100)
jpt
-148 ~ 752°F (-100 ~ 400°C)
Copper (Cu50)
Cu
-58 ~ 302°F (-50 ~ 150°C)
Nickel (Ni120)
ni
-112 ~ 572°F (-80 ~ 300°C)
*Note: Use only ungrounded thermocouples.
tpun
Temperature Unit
Range: F, C
Sets controller units to Celsius or Fahrenheit.
tp-h
Input Range High
This is the maximum value of the set point temperature range. The SV
value cannot exceed the
tp-h
value. This parameter cannot be lower
than the Input Range Low parameter (
tp-l
).
tp-l
Input Range Low
This is the minimum value of the set point temperature range. The SV
value cannot be set lower than the
tp-L
value. This parameter cannot
be higher than the Input Range High parameter (
tp-h
).
