 Precaution
• The preset value (default) of the changed operation mode is set when changing P-2
OUT operation mode setting.
• Preset value is converted as the changed unit automatically when changing P-1
Display unit setting.
• Preset is reset when changing P-9 External input terminal setting.
 
 Preset
 Static 
0.1 kPa 0.1 kPa 1 kPa 0.1 kPa
Hysteresis
HYsM
ST1
-50.0 50.0 500 50.0
HYS1
0.0 0.0 0 -50.0
ST2
-50.0 50.0 500 50.0
HYS2
0.0 0.0 0 -50.0
Window
comparison
output
WIN
LO-1
0.0 0.0 0 -50.0
HI-1
-50.0 50.0 500 50.0
LO-2
0.0 0.0 0 -50.0
HI-2
-50.0 50.0 500 50.0
Hysteresis-
Window
comparison
output
HY-W
ST1
-50.0 50.0 500 50.0
HYS1
0.0 0.0 0 -50.0
LOW
0.0 0.0 500 -50.0
HIGH
-50.0 50.0 0 50.0
Auto
sensitivity
setting
AUTO
ST1
0.0 0.0 0 -50.0
ST2
-50.0 50.0 500 50.0
SET
-25.0 25.0 250 0.0
Forced output
control
fOUT
-
 Preset 
Hysteresis
HYsM
Pressure
detection level 1
ST1
Min. display pressure ＜ ST1 ≤ Max. display
pressure
Hysteresis level 1
HYS1
Min. display pressure ≤ HYS1 ＜ ST1
Pressure
detection level 2
ST2
Min. display pressure ＜ ST2 ≤ Max. display
pressure
Hysteresis level 2
HYS2
Min. display pressure ≤ HYS2 ＜ ST2
Window
comparison
output
01)
WIN
Pressure
detection low
limit 1
LO-1
Min. display pressure ≤ LO-1 ≤ Max.
display pressure -(3 × Min display interval)
Pressure
detection high
limit 1
HI-1
LO-1 + (3 × Min display interval) ≤ HI-1 ≤
Max. display pressure
Pressure
detection low
limit 2
LO-2
Min. display pressure ≤ LO-2 ≤ Max.
display pressure - (3 × Min display interval)
Pressure
detection high
limit 2
HI-2
LO-2 + (3 × Min display interval) ≤ HI-2 ≤
Max. display pressure
Hysteresis-
Window
comparison
output
02)
HY-W
Pressure
detection level 1
ST1
Min. display pressure ＜ ST1 ≤ Max. display
pressure
Hysteresis level 1
HYS1
Min. display pressure ≤ HYS1 ＜ ST1
Pressure
detection low
limit
LOW
Min. display pressure ≤ LOW ≤ Max.
display pressure - (3 × Min display interval)
Pressure
detection high
limit
HIGH
Low + (3 × Min display interval) ≤ HIGH ≤
Max. display pressure
Auto
sensitivity
setting
AUTO
Pressure level 1
ST1
Min. display pressure ≤ ST1 ≤ Max. display
pressure - 1% of rated pressure
Pressure level 2
03)
ST2
ST1 + 1% of rated pressure ≤ ST2 ≤ Max.
display pressure
Pressure
detection level
SET
Auto setting
(ST1+ST2)
2
SET=
• Manual setting is possible by [▼] or [▲]
key.
Forced output
control
04)
fOUT
- -
• Manual ON/OFF for OUT1/2 is possible by
[▼] or [▲] key.
01) Hysteresis: 1 (min display interval, 󹃒xed)
02) ST1 = HYS1, actual hysteresis is 1 (min. display interval)
03) When error appears, check setting conditions and set proper setting values.
04) [Option external input model] Forced output does not support external input terminal.

 
• Setting name and value are cross-displayed in SV display part.
1. Set the operation mode in P-2 OUT operation mode.
2. Enter the preset setting mode by pressing [M] key from RUN mode.
3. Select the setting item by [M] key and change the preset by [▼] or [▲] key.
4. Press [M] key to save setting or no key input over 60 sec not to save setting and
return to RUN mode. (except forced output control mode)
 

Change the output operation mode to change pressure detection method.
  Hysteresis  Min display interval 
 Hysteresis  
• Set the hysteresis for pressure detection
directly.
• Setting: Pressure detection level (ST1,
ST2), Hysteresis (HYS1, HYS2)
• It detects pressure at the desired range.
• Hysteresis is 󹃒xed as min. display
interval.
• Setting: High limit (HI1, HI2), Low limit
(LO1, LO2)
Pressure
ST2 / HYS2
ST1 / HYS1
OUT2 N.O.
ST2 / HYS2
OUT1 N.O.
ST1 / HYS1
OUT2 N.C.
ST2 / HYS2
OUT1 N.C.
ST1 / HYS1
Time
H
H
Pressure
LO2
HI2
LO1
HI1
OUT2 N.O.
LO2 / HYS2
OUT1 N.O.
LO1 / HYS1
OUT2 N.C.
LO2 / HYS2
OUT1 N.C.
LO1 / HYS1
Time
A
A
A
A
 
  
• It is available both hysteresis mode
and window comparison output mode
operations.
• Setting: Pressure detection level (ST1),
Hysteresis (HYS1), High limit (HIGH), Low
limit (LOW)
• This function is to set the proper position
(SET) automatically by applied pressure
from two positions (ST1, ST2).
(ST1+ST2)
2
SET=
• Hysteresis is 󹃒xed as min. display
interval.
Pressure
LOW
HIGH
HYS1
ST1
OUT2 N.O.
LOW / HIGH
OUT1 N.O.
ST1 / HYS1
OUT2 N.C.
LOW / HIGH
OUT1 N.C.
ST1 / HYS1
Time
A
A
Pressure
SET
ST2
ST1
OUT1 N.O.
ST1/ST2
OUT2 N.O.
SET
OUT1 N.C.
ST1/ST2
OUT2 N.C.
SET
Time
A
A
A
 
• It displays the present pressure with
forcibly holding comparing output OFF
regardless of setting value.
• Manual ON/OFF for OUT1/2 is possible
by [M], [▼] or [▲] key during forced
output control operation.
OUT1
  
[M]
  
OUT2
Time
Time
[M]
