2 Modbus Mapping Table
© Copyright Reserved Autonics Co., Ltd. 19
2 Modbus Mapping Table
2.1 Read coil status/Force single coil
No(Address) Func R/W Parameter
Description Setting Range Unit
Factory
Default
Note
000001 to 000050
01/05
R/W
Reserved
2.2 Read input status
No(Address) Func R/W Parameter
Description Setting Range Unit
Factory
Default
Note
100001 (0000)
02
R
RUN lamp Operation indicator 0: OFF 1 : ON
-
-
100002 (0001) 02 R
MAN lamp Manual control indicator 0: OFF 1 : ON
- -
100003 (0002)
02
R
ALM lamp Alarm output indicator 0: OFF 1 : ON
-
-
100004 (0003) 02 R
OUT lamp Control output indicator 0: OFF 1 : ON
- -
100005 (0004)
02
R
V lamp Unit indicator 0: OFF 1 : ON
-
-
100006 (0005) 02 R
A lamp Unit indicator 0: OFF 1 : ON
- -
100007 (0006)
02
R
DI-1 input DI-1 input status 0: OFF 1 : ON
-
-
100008 (0007)
02
R
DI-2 input DI-2 input status 0: OFF 1 : ON
-
-
100009 (0008)
02
R
DI-3 input
DI-3 input status
0: OFF
1 : ON
-
-
100010 to 100050
02
R
Reserved
