Autonics SPR Series User Manual

2 Modbus Mapping Table
© Copyright Reserved Autonics Co., Ltd. 21
No(Address) Func R/W Parameter
Description Setting Range Unit
Factory
Default
Note
OUT lamp
Control output indicator
0: OFF 1 : ON
- - Bit 3
V lamp
Unit indicator
0: OFF 1 : ON
- - Bit 4
A lamp
Unit indicator
0: OFF 1 : ON
- - Bit 5
RUN D/I
RUN contact input status
0: OFF 1 : ON
- - Bit 6
AUTO D/I
AUTO contact input status
0: OFF 1 : ON
- - Bit 7
RESET D/I
RESET contact input status
0: OFF 1 : ON
- - Bit 8
301009 (03F0)
※
2
04 R
Fuse Alarm
Fuse break alarm
0: OFF 1 : ON
- - Bit 0
Over Curr
Alarm
Overcurrent alarm
0: OFF 1 : ON
- - Bit 1
Over Volt
Alarm
Overvoltage alarm
0: OFF 1 : ON
- - Bit 2
Heat Sink
Alarm
Heatsink overheat alarm
0: OFF 1 : ON
- - Bit 3
SCR Alarm
SCR error alarm
0: OFF 1 : ON
- - Bit 4
Heater Break
Alarm
Heater break alarm
0: OFF 1 : ON
- - Bit 5
※1. 301008 (03EF) address data organization
Bit F
Bit E
Bit D
Bit C
Bit B
Bit A
Bit 9
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
- - - - - - - RESET
intput
AUTO
intput
RUN
intput
A
indicator
V
indicator
OUT
indicator
ALM
indicator
MAN
indicator
RUN
indicator
0
0
0
0
0
0
0
0 / 1
0 / 1
0 / 1
0 / 1
0 / 1
0 / 1
0 / 1
0 / 1
0 / 1
1Byte
1Byte
※2. 301009 (03F0) address data organization
Bit F
Bit E
Bit D
Bit C
Bit B
Bit A
Bit 9
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
- - - - - - - - - - Heater
break
SCR
error
Heatsink
overheat
Over-
voltage
Over-
current
Fuse
break
0
0
0
0
0
0
0
0
0
0
0 / 1
0 / 1
0 / 1
0 / 1
0 / 1
0 / 1
1Byte
1Byte
