Autonics TC4S User Manual

H-56
TC Series
(unit: mm)

Dimensions
TC4M TC4H/L
1
7
2
8
3
9
4
5
6
10
11
12
13
14
15
16
17
18
SSR OUT:
12VDC ±2V
20mA Max.
※
1
SOURCE:
100-240VAC
5VA 50/60Hz,
24VAC 5VA 50/60Hz,
24-48VDC 3W
B' RTD TC
SENSOR
AL1 OUT:
250VAC
1A 1a
AL2 OUT:
250VAC
1A 1a
Relay OUT:
250VAC 3A 1a
B
A
13
19
14
20
15
21
16
22
17
23
18
24
SSR OUT:
12VDC ±2V
20mA Max.
※
1
SOURCE:
100-240VAC
5VA 50/60Hz,
24VAC 5VA 50/60Hz,
24-48VDC 3W
B' RTD TC
SENSOR
AL1 OUT:
250VAC
1A 1a
AL2 OUT:
250VAC
1A 1a
Relay OUT:
250VAC 3A 1a
B
A
1
7
2
8
3
9
4
10
5
11
6
12
※
1: AC power: 100-240VAC 5VA 50/60Hz
AC/DC power: 24VAC 5VA 50/60Hz, 24-48VDC 3W
TC4S TC4SP
TC4Y
TC4M TC4H
TC4W
48
45
64.56 48 58.5 45
72.2
6
72 77
84
7
36 30
48
44.7
64.596 6
64.5
67.5
72 6
96
91.5
48
64.56

Autonics TC4S Specifications

General

Dimensions	48 x 48 mm
Display Accuracy	±0.3% FS ±1 digit
Sampling Period	100 ms
Mounting	Panel mount
Control Method	ON/OFF control, P control, PI control, PD control, PID control
Input Type	Thermocouple, RTD
Power Supply	100-240VAC~ 50/60Hz
Output Type	Relay, Current
Display	7-segment LED
Operating Ambient Temperature	-10 to 50°C
Resolution	0.1°C or 1°C
Storage Temperature	-20 to 60°C (with no icing)
