11
NOTE
The pulse width system is preset to 3ms, no need to set it
again.
Simulate whether the fuel injectors drip and leak when the oil
pressure of the vehicle is 0.3Mpa.
07 Leakage Test
Press the item selection up and down keys to select the “07
Leakage test” item.
Press the working time selection keys to set the time. (Gener-
ally set to 1 minute)
The remaining operation steps are consistent with item 02.
Press the item selection up and down keys to select the item
“09 Middle-speed fuel injecting amount test.
The rest of the operation steps are consistent with item 08.
09 Middle-speed Fuel Injecting Amount Test
NOTE
Simulates the working condition and injection amount of the
engine at idle speed when the injectors work a certain number
of times.
08 Idle Fuel Injecting Amount Test
Press the item selection up and down keys to select the “08
Idle fuel injecting amount test” item.
The remaining operation steps are consistent with item 02.
10s, and the user does not need to set it separately.
The system will automatically and continuously cycle three
times to simulate the working condition and fuel injection
volume of the fuel injector when the engine is idling, medium
speed, and high speed.
