6 Heat
ing Mode
7 Heating Cycle
Indoor Unit
Outdoor Unit
Ind
oor heat exchanger
(Evaporation)
C
om
pressor
(Compression)
Out
door heat exchanger
(Condensation)
C
ap
illary
(Throttling)
S
team-gas of low
pressure
S
up
er cooled liquid of high
pressure
Super cooled liquid of
low pressure
G
as of high pressure
& temperature
4
-way valve
(Heat pump only)

AUX Q Series Specifications

General

Refrigerant	R32
Energy Efficiency Class Cooling	A++
Energy Efficiency Class Heating	A+
Type	Split System
Features	Sleep Mode, Turbo Mode, Self-Cleaning
Energy Rating	5 Star
Filter Type	Anti-Bacterial Filter
Warranty	5 Years
Cooling Capacity	12000 BTU/h
Heating Capacity	12000 BTU/h
