AUX Q Series User Manual

65
10.
Exploded Views and Parts List
10-1 Indoor Unit
Part List
NO.
Part
Name
E
R
P
Q
uan
tity
N
O.
P
art Name
E
RP
Q
uan
tity
1
pa
nel 1 13
Evaporator
assembly
1
2
D
isplay board 1 13.1
Evaporator left
side carriage
1
3
A
ir louver 1 13.2 Evaporator part A 1
4
F
ilter 2 13.3 Evaporator part B 1
5
Me
dium frame
decorative strip
1 14 Motor cover 1
6
Le
ft side panel 1 15 IDU Motor 1
7
Me
dium frame 1 16
Mounting plate
assembly
1
8
Right side panel 1 17 Pipe clamp 1
9
Chassis assembly 1 19 Main controller 1
9
.1
Ma
nual louver
link
1 19.3 Control box 1
9
.2 ai
r blade 2 19.4 Main control board
1

AUX Q Series Specifications

General

Refrigerant	R32
Energy Efficiency Class Cooling	A++
Energy Efficiency Class Heating	A+
Type	Split System
Features	Sleep Mode, Turbo Mode, Self-Cleaning
Energy Rating	5 Star
Filter Type	Anti-Bacterial Filter
Warranty	5 Years
Cooling Capacity	12000 BTU/h
Heating Capacity	12000 BTU/h
