AUX Q Series User Manual

11
5-2 Cooling & Heating
4 Cool
ing Mode
5 Cooling Cycle
Indoor Unit Outdoor Unit
I
nd
oor heat exchanger
(Evaporation)
C
o
m
pressor
(Compression)
O
ut
door heat exchanger
(Condensation)
C
ap
illary
(Throttling)
S
team-gas of low pressure
S
uper cooled liquid of high
pressure
L
iquid of low
pressure
(also a little gas)
G
as of high pressure
& temperature
4
-way valve
(Heat pump only)

AUX Q Series Specifications

General

Refrigerant	R32
Energy Efficiency Class Cooling	A++
Energy Efficiency Class Heating	A+
Type	Split System
Features	Sleep Mode, Turbo Mode, Self-Cleaning
Energy Rating	5 Star
Filter Type	Anti-Bacterial Filter
Warranty	5 Years
Cooling Capacity	12000 BTU/h
Heating Capacity	12000 BTU/h
