31
SPECIFICATIONS
Model Dual voltage
Line input power: 120 VAC/240/208 VAC
Output power:
16 Amps continuous @ 120VAC
16 Amps continuous @ 240/208VAC
Circuit breaker rating:
20 Amp @ 120 VAC
20 Amp @ 240 VAC
Frequency 60 Hz
Power draw at idle
during charging
< 2 watts
< 4 watts
Cable length: approximately 20 ft. (6.1 m)
Weight:
5.5 lbs. (2.49 kg) - module
28.5 lbs (12.92 kg) - pedestal
2.5 lbs (1.13 kg) - wall mount bracket
Temperature - operating -40°C to +50°C (-40°F to 122°F)
Temperature –
storing and transporting:
-40°C to +70°C (-40°F to +140°F)
Environmental rating: NEMA 3R
Vehicle – Dual voltage charger
communication protocol:
SAE J1772 compliant
Charge coupler: SAE J1772 compliant
Direction of charge: Grid to vehicle
Specifications are subject to change without notice.
